Aruba Access Point-AP 303P-Indoor-TPM-WiFi 5-Internal Antenna -2x2 MU MIMO-OFDMA-Dual band -ARM-IOT Capabilities-Bluetooth 5.0-Zigbee-Aruba Instant OS

The midrange 303P Series access points support high-performance 802.11ac with multiuser MU-MIMO (Wave 2). These series reduce the total cost of ownership for enterprises by integrating BLE and 802.3af power.

Compact design delivers 867 Mbps in 5GHz and 300 Mbps in 2.4GHz (1.2Gbps aggregate peak data rate).  The 2x2:2SS design makes it suitable for medium-density environments, including schools, retail stores, warehouses, hotels, and corporate offices.

SPECIFICATION:

KEY FEATURES:

• Up to 1.2 Gbps aggregate peak data rate
• Daisy-chaining another AP's PoEout port
• With Zigbee and Bluetooth 5, IoT can be connected
• ClientMatch offers MU-MIMO support to solve sticky client issues
• Contributes to dynamic Segmentation solutions at Aruba

UNIQUE FEATURE:

• Unified AP – controller-based or controller-less - these Series support ArubaOS or InstantOS.

• MU MIMO (wave 2) dual radio 802.11ac access point. Supports 867Mbps at 5GHz and 300Mbps at 2.4GHz (with 2SS/HT40 clients).

• Built-in Bluetooth Low-Energy (BLE) - Enables multiple beacons to work together and tracks assets with asset tags

•  Advanced Cellular Coexistence (ACC) - Simplifies collaboration between 3G/4G cellular networks, distributed antenna systems, small cells, and femtocells

• Adaptive Radio Management (ARM) -  AirMatch optimizes radio channel settings for reliable, high-performance WLAN based on the environment and client density.

• Aruba Secure Core -Device assurance: Credentials and keys are stored securely via Trusted Platform Modules (TPM).

1. Integrating wireless intrusion protection into security appliances eliminates the need for separate RF sensors.
2. With IP reputation and security services, advanced online threats can be identified, classified, and blocked

AP-303P can power any network device (IP camera, IoT gateway, or second Access Point) using its Ethernet port E1. Share switch ports and cabling to simplify installation and reduce costs.

OPERATING MODES

• Provides maximum flexibility by supporting controller-based and controller-less deployment modes.
• Controller-based mode provides centralized configuration, encryption, policy enforcement, and network services through Aruba Mobility Controllers.
• Controller-less (Instant) mode virtualizes the controller function by clustering APs. When the network grows, it is easy to migrate to controller-based deployments.
• Deploying branches via Remote Access Points (RAP)
• Rogue detection and containment using air monitors (AMs)
• Identifying sources of RF interference with a spectrum analyzer (SA)

OTHER FEATURES

Wifi: AP 303P: dual radio, 5GHz 802.11ac 2x2 MIMO and 2.4GHz 802.11n 2x2 MIMO

   5GHz (radio 0): 

• Using two spatial streams MIMO, individual 2SS VHT80 clients can receive up to 867 Mbps wireless data.
• With two spatial streams, two 1SS MU-MIMO capable client devices can receive wireless data at 867 Mbps.

   2.4GHz (radio 1):

        With two spatial streams and SU MIMO,  HT40 2SS  transmit up to  300 Mbps wirelessly.

• Up to 256 clients can be associated with each radio, and each radio can support up to 16 BSSIDs
• Receiver performance improved by maximum ratio combining (MRC)
• Downlink RF performance can be improved with a CDD/CSD diversity scheme
• A short guard interval channel (10MHz, 20MHz, 80MHz)
• With space-time block coding, the range and reception are improved
• LDPC increases throughput and error correction efficiency
• Signal range and reliability are increased by transmit beam-forming (TxBF)

WIFI Antenna:

• Dual-band vertically polarized downtilt omnidirectional antennas with peak antenna gain of 3.4dBi at 2.4GHz and 7.8dBi at 5GHz.

• When combining both antenna patterns per radio, the peak gain of the average (effective) pattern is 2.1dBi in 2.4GHz and 5.9dBi in 5GHz.

Horizontal planes (top view) show azimuth patterns (0 degrees) and downtilt patterns (30 degrees)

EXTERNAL  FEATURES:

RJ45  Port:

E0:  Ethernet network interface with the capabilities of 10/100/1000BASE-T (RJ-45) 

• Automatic detection of link speed and MDI/MDX 
• Ethernet Energy Efficient (EEE) based on IEEE 802.3az 
•  PoE-PD is 48V dc (nominal) 802.3at/bt PoE

E1: RJ-45 Ethernet network interface capable of 10/100/1000BASE-T

•  Automatic detection of link speed and MDI/MDX 
• Ethernet Energy Efficient (EEE) based on IEEE 802.3az 
•  PoE-PSE is 48V dc (nominal) 802.3at/at PoE

Visual indicators:  Tri-colored LEDs for system and radio status

Reset button: Factory reset (during device startup), LED mode control (normal/off).

Serial console interface:  physical USB port, proprietary

POWER SOURCE:

• Supports both direct DC power and Power over Ethernet (PoE).
• When both are available, DC power is preferred over PoE.
• DC input 12 volts nominal, tolerance +/-5%
• 2.1/5.5 mm center-positive and 9.5 mm length circular plugs are accepted by the DC power interface
• PoE (Power over Ethernet): 48Vdc (nominal) source compliant with IEEE 802.3af
• Maximum power consumption (worst-case): 10.1W (PoE) or 8.8W (DC).
• Power consumption (worst-case) in idle mode: 4.2W (PoE) or 4.0W (DC).

NOTE1: Power source has to be purchased separately.

NOTE2: In terms of reliability, the MTBF is 518 khrs (59 years) at +25C.

MINIMUM REQUIREMENT:

MECHANICAL DETAILS:

➢ Dimensions: 150mm (W) x 150mm (D) x 35mm (H) ➢ Weight: 280g

Shipping: ➢ Dimensions:190mm (W) x 180mm (D) x 60mm (H) ➢ Weight:430g
